abouT ...
2.1.2 Additional useful technical documentation
Apart from the operating instructions you already have, further documentation is available for the
v
2
eagle,e.g.documentationconcerningconguration.Alldocumentationcanbedownloaded
from the Crane Payment Innovations website (www.cranepi.com, Support)aspdfle.
2.2 About the v
2
eagle
The v
2
eaglecoinvalidatorwithparallelBDTA/BACTAinterfaceinthestandardized5“format
uses the patented multi-frequency technology (MFT) for reliable coin validation. Communication
with the vending machine control system takes place via the 16-pin BDTA or the 17-pin BACTA
connector. Due to its modular, compact design the v
2
eagle is ideally suited for gaming, vending
and service machines.
For coin acceptance the coin validator has 32 coin channels which – divided into 2 x 16 coin
channels – can be managed in two memory blocks with different coin congurations and
selected individually.
Depending on the application, the coin validator can optionally be equipped with a 4-fold or
5-fold sorter.
To be able to react as quickly as possible to new false coins and to make your individual settings,
thecoinvalidatorcanbeconguredonsiteinthemachineusingaservicetoolorintheworkshop
via a PC programming station.
Any coins or tokens not taken into account by the manufacturer can be programmed in the optional
teachmodedirectlyonthecoinvalidatorwithoutanycongurationsoftwarebyinsertingthecoins.
2.2.1 The v
2
eagle features
• Reliable acceptance of genuine coins and rejection of false coins due to MFT multiple
sensing of the coins inserted and evaluation of 24 measuring parameters
• Operating and manipulation safety provided by optical accepted coin sensors and sorting
control in the coin validation and coin outlet area
• Acceptance speed of two coins per second
• 32coinchannelsmanagedintwoindependentlyconguredandindividuallyselectable
memory blocks (2 x 16 coin channels)
• Service interface for PC programming station or on-site service tool
• Flashtechnologyforeasyandtime-savingrmwareupdates(CXash))
• Options
– teach mode for eight coin channels
– string sensor
– top or front entry, front or bottom return
– front plate
– 4-fold or 5-fold sorting mechanism
– passive 4-way both or active 8-way manifold for 4-fold sorting mechanism
– various return levers depending on machine type
