10.2.3 Sorter override interface (only BACTA)
Pin I/O Function Level
1 – Ground (GND)
– Polarising key
3 IN Full-signal line, path 7, active low
4 IN Full-signal line, path 6, active low
5 IN Full-signal line, path 5, active low
6 IN Full-signal line, path 4, active low
7 IN Full-signal line, path 3, active low
8 IN Full-signal line, path 2, active low
9 IN Full-signal line, path 1, active low
10 – Operating voltage = +10 V–24 V DC
10.2.4 v² eagle – 8-fold manifold (option, only BACTA 4-fold sorter)
Pin Function Level
1 GND, switched GND
Polarising key -
3 Supply voltage U
++
lo
