Table of conTenTs
4
BA_v2_eagle_parallel_EN_1-0
5 Function 20
5.1 Coin acceptance and coin channels 20
5.2 Memory blocks 21
5.3 Accepted coin sensor and sorting control 21
5.4 Transmission of coin values via coin pulses and coin signal lines 22
5.4.1 Multiple pulses 22
5.4.2 Coin pulse length 22
5.4.3 Tow assignments of the BACTA machine interface
(standard and binary mode) 23
5.4.3.1 Binary mode 23
5.4.3.2 Standard mode 23
5.5 Coin-in mech signal (CIMS) (option, not standard BACTA mode) 23
5.6 Coin inhibition/activation of narrow coin channels 24
5.6.1 Inhibiting all coins via the machine control system
(common inhibit) 24
5.6.2 Inhibiting individual coins/coin channels via the machine
control system (single inhibit) 24
5.6.3 Inhibiting individual coins/coin channels via the switch blocks 24
5.7 Sorting accepted coins (option) 25
5.7.1 Sorting principle of 5-fold in-line sorter (Ex8xPx. ..)
(not with BACTA interface) 25
5.7.1.1 Sorting with NRI 4-way manifold (option) 26
5.7.2 Sorting principle of 4-fold sorter (Ex7xPx. ..)
(not with BDTA interface) 27
5.7.2.1 Sorting with Money Controls 4-way manifold 28
5.7.2.2 Sorting with active Money Controls 8-way manifold 29
5.7.3 Sorter override for tube-full signal via ... 30
5.7.3.1 ... Single inhibit lines of BDTA interface 30
5.7.3.2 ... Sorter override interface (only BACTA) 30
5.8 Teach mode (option) 30
5.9 Manipulation detection (option) 31
5.9.1 Foul signal (only v² eagle BACTA) 31
5.9.2 String recognition 31
6 Start-up 32
