NRI v2 eagle - Page 5

Table of conTenTs
BA_v2_eagle_parallel_EN_1-0
5
7 Operation 34
7.1 Selecting the memory block ... 34
7.1.1 ... using the switch block on the coin validator 34
7.1.2 ... via machine control (option, only BDTA interface) 34
7.2 Inhibiting coins/activating narrow coin channel 35
7.2.1 Inhibit functions – switch block S1 35
7.2.2 Inhibit functions – switch block S2 35
7.3 Teaching coin channels in teach mode (optional) 37
8 Maintenance and service 39
8.1 Cleaning measurement and validation area 39
8.2 Troubleshooting 41
9 What subsequent settings can be made? 42
9.1 Serviceandcongurationtools 42
9.1.1 PCcongurationsoftwareheartbeat 42
9.1.2 On-site service tool HENRI
+
42
9.2 Which device functions can be set? 42
10 Technical data 44
10.1 Device data 44
10.2 Interfaces 46
10.2.1 BDTA interface 46
10.2.1.1 BDTA pin assignment 46
10.2.1.2 BDTA interface description 47
10.2.1.3 BDTA connection diagram 47
10.2.2 BACTA interface 48
10.2.2.1 BACTA pin assignment, binary mode 48
10.2.2.2 BACTA pin assignment, standard mode 49
10.2.2.3 BACTA interface description 49
10.2.3 Sorter override interface (only BACTA) 50
10.2.4 v² eagle – 8-fold manifold (option, only BACTA 4-fold sorter) 50
10.3 Accessories 51
10.3.1 Front plates 51
10.3.2 Manifolds/sorters 52
10.3.3 Service tools 53
11 Index 54
