NRI v2 eagle - Page 33

BA_v2_eagle_parallel_EN_1-0
33
sTaRT-up
3
3
3
3
3
3 3
3
1
1 1
1
2
2
2
4
Fig. 12: BDTA installation
1 Switch block
2 Interface – machine (BDTA)
3 Mounting stud
Fig. 13: BACTA installation
1 Switch block
2 Interface – machine (BACTA)
3 Mounting stud
4 Interface – sorter override
4-fold sorter
4-fold sorter
(not yet available)
5-fold in-line sorter
5-fold in-line sorter
2
