Nvidia ConnectX-7 User Manual

105
Pin# Signal Name Wire Type AWG# Detailed
Description
Pin# on the
other end
58
S_PERST1_CONN_L
Micro coax 38 PCIe compliant
PERST_L (active low
PCI Reset) signal for
the PCIe Cabline CA-
II Plus Connectors.
The direction of this
PERST_L signal
depends on the
implementation:
When connecting a
CPU root complex to
the PCIe Cabline CA-
II Plus interface, this
signal is driven from
the motherboard
side (from the CPU),
to the network
adapter. When
connecting a GPU or
an end point to the
PCIe Cabline CA-II
Plus interface, this
signal is driven from
the network adapter
side (which operates
as a PCIe switch in
this case), to the
GPU or end-point on
the motherboard
side.
58
59 No Wire 59

Nvidia ConnectX-7 Specifications

General

Supported Protocols	Ethernet, InfiniBand
RoHS Compliance	Yes
Ports	1 or 2 ports
Data Transfer Rate	Up to 400 Gb/s
Ethernet Speeds	10/25/40/50/100/200/400
InfiniBand Speeds	400Gb/s
Latency	Sub-600 nanoseconds
Form Factor	OCP 3.0
Product Type	Network Interface Card (NIC)
Power Consumption	Varies by model and configuration
