Nvidia ConnectX-7 User Manual

81
MCX713104AC-ADAT and MCX713104AS-ADAT
Specifications
Physical
PCIe Half Height, Half Length2.71 in. x 6.6 in. (68.90mm x 167.65 mm)
Connector: Quad-port SFP28 Ethernet (copper and optical)
Interfaces
SeeSupported Interfaces
PCI Express Gen 4.0: SERDES @ 16GT/s, x16 lanes (4.0 and 3.0 compatible)
Networking Port: Quad-port SFP56 Ethernet (copper and optical)
Protocol
Support
Data Rate Ethernet 50/25GbE
Ethernet Protocols: 50GAUI-2 C2M, 50GAUI-1 C2M, 50GBASE-CR, 50GBASE-R2 , 40GBASE-
CR4, 40GBASE-R2, 25GBASE-R, 10GBASE-R, 10GBASE-CX4, 1000BASE-CX, CAUI-4 C2M,
25GAUI C2M, XLAUI C2M , XLPPI, SFI
Capabilities
MCX713104AC-ADAT: Secure Boot Enabled, Crypto Enabled
MCX713104AS-ADAT: Secure Boot Enabled, Crypto Disabled
Electrical and
Thermal
Specifications
Voltage: 12V, 3.3VAUX
Maximum current:100mA
Maximum power available through Quad-port SFP56: TBD
Power and airflow specifications are provided in NVIDIA ConnectX-7 Electrical and Thermal
Specificationsdocument, which is available at NVOnline following login.
Environmental
Temperatur
e
Operationa
l
0°C to 55°C
Non-
operationa
l
-40°C to 70°C
Humidity Operationa
l
10% to 85% relative humidity
Non-
operationa
l
10% to 90% relative humidity
Altitude
(Operationa
l)
3050m
Regulatory
Safety: CB / cTUVus / CE
EMC: CE / FCC / VCCI / ICES / RCM / KC
RoHS: RoHS Compliant
MCX713114TC-GEAT and MCX713114GC-GEAT
Specifications
Physical
Adapter Card Size:Full Height Half Length -4.53 in. x 6.6 in. (115.15 mm x 167.65 mm)

Nvidia ConnectX-7 Specifications

General

Supported Protocols	Ethernet, InfiniBand
RoHS Compliance	Yes
Ports	1 or 2 ports
Data Transfer Rate	Up to 400 Gb/s
Ethernet Speeds	10/25/40/50/100/200/400
InfiniBand Speeds	400Gb/s
Latency	Sub-600 nanoseconds
Form Factor	OCP 3.0
Product Type	Network Interface Card (NIC)
Power Consumption	Varies by model and configuration
