Nvidia ConnectX-7 User Manual

97
Pin# Signal Name Wire Type Detailed
Description
AWG# Pin# on the
other end
58
I2C_AUX_SDA
Micro coax The ConnectX-7
silicon serves as the
I2C bus master on
this bus. An I2C
EEPROM at I2C
address 0x57 needs
to be mounted on
the motherboard
side to report to the
Cabline CA-II Plus
interface parameters
to the main-card
network adapter
silicon, like Cabline
CA-II Plus cables
length (contact
NVIDIA for the
format of this
EEPROM). If
additional optional
I2C slave devices
need to be managed
by the main-card
network adapter
silicon, they need to
be included on this
I2C bus as well.
38 58
59 S_PRSNT1_L Micro coax
Connect this pin to
GND
No wires are
connected to these
pins to ensure they
do not interfere with
the operation of
S_PRSNT2_L for the
detection when the
two Cabline
harnesses are
installed.
38 59
60 No Wire 60
Print Side
Pin# Signal Name Wire Type AWG# Detailed
Description
Pin# on the
other end
1 SER_CLK Micro coax 38 1
2 SER_CAPTURE Micro coax 38 2
3 SER_DO Micro coax 38 3

Nvidia ConnectX-7 Specifications

General

Supported Protocols	Ethernet, InfiniBand
RoHS Compliance	Yes
Ports	1 or 2 ports
Data Transfer Rate	Up to 400 Gb/s
Ethernet Speeds	10/25/40/50/100/200/400
InfiniBand Speeds	400Gb/s
Latency	Sub-600 nanoseconds
Form Factor	OCP 3.0
Product Type	Network Interface Card (NIC)
Power Consumption	Varies by model and configuration
