98
Pin# Signal Name Wire Type AWG# Detailed
Description
Pin# on the
other end
4 Reserved_04 Micro coax 38 4
5 SER_DI Micro coax 38 5
6 S_BIFFURCATE_AUX_BRD Micro coax 38 In specific Network
Card Assemblies
which support
bifurcation of the
PCIe x16 IPEX
interface to two x8
PCIe interfaces, this
pin is used for either
the motherboard or
the network adapter
silicon to signal
whether the IPEX
interface should or
should not be
bifurcated. This
signal has been
reserved and hasn’t
been used in the
past, and as a result
it’s direction has not
been fixed yet, to
provide for
additional options in
the future. (pin is
marked as Reserved
06 in the generic
White IPEX Cable
pinout)
6
7 Reserved_07 Micro coax 38 Reserved for future
expansion
7
8 Reserved_08 Micro coax 38 Reserved for future
expansion
8
9 GND GND BAR 9
10 PCIE_CX_CPU_0P Micro coax 38 Connect from the
White Cabline CA-II
Plus harness to the
PCIe x16 Rx lanes of
the CPU/GPU/End-
Point. 220nF caps
are required on this
signal on the
ConnectX-7 card.
10
11
PCIE_CX_CPU_0N
Micro coax 38 Connect from the
White Cabline CA-II
Plus harness to the
PCIe x16 Rx lanes of
the CPU/GPU/End-
Point. 220nF caps
are required on this
signal on the
ConnectX-7 card.
11
