Nvidia ConnectX-7 User Manual

32
Connect the adapter Card in an available PCI Express x16 slot in the chassis.
Step 1:Locate an available PCI Express x16 slot and insert the adapter card to the chassis.
Step 2:Applying even pressure at both corners of the card, insert the adapter card in a PCI
Express slot until firmly seated.
Secure the adapter card to the chassis.
Securethebrackettothechassiswiththebracketscrew.
Uninstalling the Card
Safety Precautions
The below images are for illustration purposes only.

Do not use excessive force when seating the card, as this may damage the chassis.


Nvidia ConnectX-7 Specifications

General

Supported Protocols	Ethernet, InfiniBand
RoHS Compliance	Yes
Ports	1 or 2 ports
Data Transfer Rate	Up to 400 Gb/s
Ethernet Speeds	10/25/40/50/100/200/400
InfiniBand Speeds	400Gb/s
Latency	Sub-600 nanoseconds
Form Factor	OCP 3.0
Product Type	Network Interface Card (NIC)
Power Consumption	Varies by model and configuration
