Nvidia ConnectX-7 User Manual

40
Step 3:Applying even pressure at both corners of the cards, insert the Auxiliary Connection
card inthe PCI Express slots until firmly seated.
Secure the ConnectX-7 adapter and PCIe Auxiliary Connection Cards to the chassis.
Step 1: Secure the brackets to the chassis with the bracket screws.
Uninstalling the Cards
Safety Precautions

Nvidia ConnectX-7 Specifications

General

Supported Protocols	Ethernet, InfiniBand
RoHS Compliance	Yes
Ports	1 or 2 ports
Data Transfer Rate	Up to 400 Gb/s
Ethernet Speeds	10/25/40/50/100/200/400
InfiniBand Speeds	400Gb/s
Latency	Sub-600 nanoseconds
Form Factor	OCP 3.0
Product Type	Network Interface Card (NIC)
Power Consumption	Varies by model and configuration
