Setting High-Speed-Port Link Type
The following table lists the ConnectX-7 cards supporting both Ethernet and InfiniBand protocols,
the supported speeds and the default networking port link type.
OPN Data Transmission Rate Default Protocol and Rate
MCX755106AS-HEAT NDR200 / 200GbE Ethernet 200GbE
To configure the networking high-speed ports mode, you can either use the mlxconfig or the UEFI
tools.
UEFI can configure the adapter card device before the operating system is up, while
mlxconfig configures the card once the operating system is up. According to your
preference, use one of the below tools:
mlxconfig
The mlxconfig tool allows users to change device configurations without burning the firmware. The
configuration is also kept after reset. By default, mlxconfig shows the configurations that will be
loaded in the next boot. For more information and instructions, refer to Using mlxconfig to Set IB/
ETH Parameters.
UEFI
PreBoot drivers initialize the adapter device, check the port protocol type – Ethernet or InfiniBand -
and bring up the port. Then it connects to a DHCP server to obtain its assigned IP address and
network parameters and obtain the source location of the kernel/OS to boot from. The DHCP server
instructs the PreBoot drivers to access the kernel/OS through a TFTP server, an iSCSI target, or some
other service. For more information and instructions, refer to UEFI.
This section applies to ConnectX-7 cards supporting both Ethernet and InfiniBand protocols -
see the relevant OPNs in the following table.
