Nvidia ConnectX-7

74
Humidity Operational 10% to 85% relative humidity
Non-
operational
10% to 90% relative humidity
Altitude
(Operational)
3050m
Regulatory
Safety: CB / cTUVus / CE
EMC: CE / FCC / VCCI / ICES / RCM / KC
RoHS: RoHS Compliant
Notes: a. The ConnectX-7 adapters supplement the IBTA auto-negotiation specification to get better
bit error rates and longer cable reaches. This supplemental feature only initiates when connected to
another NVIDIA InfiniBand product.
b.Typical power for ATIS traffic load.
c. For both operational and non-operational states.
MCX755106AC-HEAT /MCX755106AS-HEAT Specifications

Physical
Adapter Card
Size
PCIe Half Height, Half Length2.71 in. x 6.6 in. (68.90mm x 167.65 mm)
Auxiliary PCIe
Connection
Card Size
5.09 in. x 2.32 in. (129.30mm x 59.00mm)
Two Cabline CA-II Plus harnesses (white and black)
Interface
s
SeeSupported Interfaces
PCI Express
Interface
Gen 5.0/4.0: SERDES @ 16/32GT/s, x16 lanes (4.0 and 3.0 compatible)
Optional:AdditionalPCIe x16 Gen 4.0 @ SERDES 18GT/s through the PCIe
auxiliary passive card and CablineSA-II Plusharnesses
Networking
Ports
Dual QSFP112 InfiniBand and Ethernet
Data
Rate
InfiniBand NDR200/HDR/HDR100/EDR/FDR/SDR
Ethernet
(Default
Mode)
200/100/50/25/10 Gb/s
Protocol
Support
InfiniBand: IBTA v1.5
a
Auto-Negotiation: NDR200 (2 lanes x 100Gb/s per lane) port, HDR (50Gb/s per lane) port, HDR100
(2 lane x 50Gb/s per lane), EDR (25Gb/s per lane) port, FDR (14.0625Gb/s per lane), 1X/2X/4X
SDR (2.5Gb/s per lane)
Ethernet
Protocols
200GAUI-4 C2M, 200GBASE-CR4, 100GAUI-2 C2M, 100GBASE-CR4, 100GBASE-CR,
100GBASE-CR1, 50GAUI-2 C2M, 50GAUI-1 C2M, 50GBASE-CR, 50GBASE-R2,
40GBASE-CR4, 40GBASE-R2, 25GBASE-R, 10GBASE-R, 10GBASE-CX4, 1000BASE-CX,
CAUI-4 C2M, 25GAUI C2M, XLAUI C2M, XLPPI, SFI
The Socket-Direct ready cards kit does not include the PCIe passive auxiliary connection
card and two Cabline SA-II Plus harnesses. For more information, please refer toPCIe
Auxiliary Card Kit.

