Nvidia ConnectX-7 User Manual

79
MCX713106AC-CEAT andMCX713106AS-
CEATSpecifications
Physical
AdapterCard Size:PCIe Half Height, Half Length2.71 in. x 6.6 in. (68.90mm x 167.65 mm)
Interfaces
SeeSupported Interfaces
PCI Express Gen 4.0/5.0: SERDES @ 16/32GT/s, x16 lanes (4.0 and 3.0 compatible)
Networking Ports: Dual-port QSFP112 Ethernet (copper and optical)
Capabilitie
s
MCX713106
AC-CEAT
Secure Boot Enabled, Crypto Enabled
MCX713106
AS-CEAT
Secure Boot Enabled, Crypto Disabled
Protocol
Support
Data Rate Ethernet 200/100/50/40/25/10/1GbE
Ethernet Protocols: 200GAUI-4 C2M, 200GBASE-CR4, 100GAUI-2 C2M, 100GBASE-CR4, 100GBASE-
CR2, 100GBASE-CR1, 50GAUI-2 C2M, 50GAUI-1 C2M, 50GBASE-CR, 50GBASE-R2 , 40GBASE-CR4,
40GBASE-R2, 25GBASE-R, 10GBASE-R, 10GBASE-CX4, 1000BASE-CX, CAUI-4 C2M, 25GAUI C2M,
XLAUI C2M , XLPPI, SFI
Electrical
and
Thermal
Specificati
ons
Voltage: 12V, 3.3VAUX
Maximum current:100mA
Maximum power available through QSFP112 port:11W per port (Not thermally supported), 2.5W
per port (Thermally Supported)
Electrical and thermal specifications are provided in NVIDIA ConnectX-7 Electrical and Thermal
Specificationsdocument, which is available at NVOnline following login.
Environme
ntal
Temperatur
e
Operatio
nal
0°C to 55°C
Non-
operation
al
-40°C to 70°C
Humidity Operatio
nal
10% to 85% relative humidity
Non-
operation
al
10% to 90% relative humidity
Altitude
(Operationa
l)
3050m
Regulatory
Safety: CB / cTUVus / CE
EMC: CE / FCC / VCCI / ICES / RCM / KC
RoHS: RoHS Compliant

Nvidia ConnectX-7 Specifications

General

Supported Protocols	Ethernet, InfiniBand
RoHS Compliance	Yes
Ports	1 or 2 ports
Data Transfer Rate	Up to 400 Gb/s
Ethernet Speeds	10/25/40/50/100/200/400
InfiniBand Speeds	400Gb/s
Latency	Sub-600 nanoseconds
Form Factor	OCP 3.0
Product Type	Network Interface Card (NIC)
Power Consumption	Varies by model and configuration
