Physical
Adapter Card Size PCIe Half Height, Half Length2.71 in. x 6.6 in. (68.90mm x 167.65 mm)
Auxiliary PCIe
Connection Card
Size
5.09 in. x 2.32 in. (129.30mm x 59.00mm)
Two Cabline CA-II Plus harnesses (white and black)
Interfaces
SeeSupported Interfaces
PCI Express
Interface
Gen 5.0/4.0: SERDES @ 16/32GT/s, x16 lanes (4.0 and 3.0 compatible)
Optional:AdditionalPCIe x16 Gen 4.0 @ SERDES 16GT/s through the
PCIe auxiliary passive card and CablineSA-II Plusharnesses
Networking Ports Single OSFP InfiniBand
Data Rate
InfiniBand NDR/NDR200/HDR/HDR100/EDR/FDR/SDR
Protocol
Support
InfiniBand: IBTA v1.5
a
Auto-Negotiation: NDR (4 lanes x 100Gb/s per lane) port, NDR200 (2 lanes x 100Gb/s per
lane) port, HDR (50Gb/s per lane) port, HDR100 (2 lane x 50Gb/s per lane), EDR (25Gb/s per
lane) port, FDR (14.0625Gb/s per lane), 1X/2X/4X SDR (2.5Gb/s per lane)
Capabilities
Secure Boot Enabled, Crypto Disabled
Electrical
and Thermal
Specification
s
Voltage: 12V, 3.3VAUX
Maximum current:100mA
Maximum power available through OSFP port: TBD
Electrical and Thermal Specifications: TBD
Environment
al
Temperature Operational 0°C to 55°C
Non-
operational
-40°C to 70°C
Humidity Operational 10% to 85% relative humidity
Non-
operational
10% to 90% relative humidity
Altitude
(Operational)
3050m
Regulatory
Safety: CB / cTUVus / CE
EMC: CE / FCC / VCCI / ICES / RCM / KC
RoHS: RoHS Compliant
Notes: a. The ConnectX-7 adapters supplement the IBTA auto-negotiation specification to get better
bit error rates and longer cable reaches. This supplemental feature only initiates when connected to
another NVIDIA InfiniBand product.
b.Typical power for ATIS traffic load.
c. For both operational and non-operational states.
