Nvidia ConnectX-7 User Manual

82
Interfaces
SeeSupported Interfaces
PCI Express Gen 4.0: SERDES @ 16GT/s, x16 lanes (4.0 and 3.0 compatible)
Networking Port: Quad-port SFP56 Ethernet (copper and optical)
Protocol
Support
Data Rate Ethernet 50/25 GbE
Ethernet Protocols:50GAUI-2 C2M, 50GAUI-1 C2M, 50GBASE-CR, 50GBASE-R2 , 40GBASE-
CR4, 40GBASE-R2, 25GBASE-R, 10GBASE-R, 10GBASE-CX4, 1000BASE-CX, CAUI-4 C2M,
25GAUI C2M, XLAUI C2M , XLPPI, SFI
Capabilities
MCX713114T
C-GEAT
Enhanced-SyncE & PTP, PPS In/Out, Secure Boot, Crypto Enabled
MCX713114G
C-GEAT
Enhanced-SyncE & PTP Grand Master support and GNSS/PPS Out, Secure
Boot, Crypto Enabled
Electrical and
Thermal
Specifications
Voltage: 12V, 3.3VAUX
Maximum current:100mA
Maximum power available through Quad-port SFP56: 1.5Wper port, 6W in total
Electrical and Thermal Specifications: TBD
Environmental
Temperature Operationa
l
0°C to 55°C
Non-
operationa
l
-40°C to 70°C
Humidity Operationa
l
10% to 85% relative humidity
Non-
operationa
l
10% to 90% relative humidity
Altitude
(Operational)
3050m
Regulatory
Safety: CB / cTUVus / CE
EMC: CE / FCC / VCCI / ICES / RCM / KC
RoHS: RoHS Compliant
Cards Mechanical Drawings and Dimensions
Dual-port x16 QSFP112 Adapter Card Dual-port x16 QSFP112 Socket-Direct Ready
Adapter Card
All dimensions are in millimeters. The PCB mechanical tolerance is +/- 0.13mm.


Nvidia ConnectX-7 Specifications

General

Supported Protocols	Ethernet, InfiniBand
RoHS Compliance	Yes
Ports	1 or 2 ports
Data Transfer Rate	Up to 400 Gb/s
Ethernet Speeds	10/25/40/50/100/200/400
InfiniBand Speeds	400Gb/s
Latency	Sub-600 nanoseconds
Form Factor	OCP 3.0
Product Type	Network Interface Card (NIC)
Power Consumption	Varies by model and configuration
