Nvidia ConnectX-7 - MCX75510 AAS-HEAT Specifications

76
Networking
Ports
Single QSFP112 InfiniBand and Ethernet
Data
Rate
InfiniBand NDR/NDR200/HDR/HDR100/EDR/FDR/SDR
Ethernet
(Default
Mode)
400/200/100/50/25/10 Gb/s
Protocol
Support
InfiniBand: IBTA v1.5
a
Auto-Negotiation: NDR (4 lanes x 100Gb/s per lane) port, NDR200 (2 lanes x 100Gb/s per lane)
port, HDR (50Gb/s per lane) port, HDR100 (2 lane x 50Gb/s per lane), EDR (25Gb/s per lane) port,
FDR (14.0625Gb/s per lane), 1X/2X/4X SDR (2.5Gb/s per lane)
Ethernet
Protocols
400GAUI-4 C2M, 400GBASE-CR4, 200GAUI-4 C2M, 200GBASE-CR4, 100GAUI-2 C2M,
100GBASE-CR4, 100GBASE-CR, 100GBASE-CR1, 50GAUI-2 C2M, 50GAUI-1 C2M,
50GBASE-CR, 50GBASE-R2, 40GBASE-CR4, 40GBASE-R2, 25GBASE-R, 10GBASE-R,
10GBASE-CX4, 1000BASE-CX, CAUI-4 C2M, 25GAUI C2M, XLAUI C2M, XLPPI, SFI
Capabili
ties
Secure Boot Enabled, Crypto Disabled
Electric
al and
Thermal
Specific
ations
Voltage: 12V, 3.3VAUX
Maximum current:100mA
Maximum power available through QSFP112 port: TBD
Power and airflow specifications: TBD
Environ
mental
Temperature Operational 0°C to 55°C
Non-
operational
-40°C to 70°C
Humidity Operational 10% to 85% relative humidity
Non-
operational
10% to 90% relative humidity
Altitude
(Operational
)
3050m
Regulato
ry
Safety: CB / cTUVus / CE
EMC: CE / FCC / VCCI / ICES / RCM / KC
RoHS: RoHS Compliant
Notes: a. The ConnectX-7 adapters supplement the IBTA auto-negotiation specification to get better
bit error rates and longer cable reaches. This supplemental feature only initiates when connected to
another NVIDIA InfiniBand product.
b.Typical power for ATIS traffic load.
c. For both operational and non-operational states.
MCX75510AAS-HEAT Specifications 
The Socket-Direct ready cards kit does not include the PCIe passive auxiliary connection
card and two Cabline SA-II Plus harnesses. For more information, please refer toPCIe
Auxiliary Card Kit.

