Nvidia ConnectX-7 User Manual

99
Pin# Signal Name Wire Type AWG# Detailed
Description
Pin# on the
other end
12 GND GND BAR 12
13 PCIE_CX_CPU_1P Micro coax 38 Connect from the
White Cabline CA-II
Plus harness to the
PCIe x16 Rx lanes of
the CPU/GPU/End-
Point. 220nF caps
are required on this
signal on the
ConnectX-7 card.
13
14
PCIE_CX_CPU_1N
Micro coax 38 Connect from the
White Cabline CA-II
Plus harness to the
PCIe x16 Rx lanes of
the CPU/GPU/End-
Point. 220nF caps
are required on this
signal on the
ConnectX-7 card.
14
15 GND GND BAR 15
16 PCIE_CX_CPU_2P Micro coax 38 Connect from the
White Cabline CA-II
Plus harness to the
PCIe x16 Rx lanes of
the CPU/GPU/End-
Point. 220nF caps
are required on this
signal on the
ConnectX-7 card.
16
17
PCIE_CX_CPU_2N
Micro coax 38 Connect from the
White Cabline CA-II
Plus harness to the
PCIe x16 Rx lanes of
the CPU/GPU/End-
Point. 220nF caps
are required on this
signal on the
ConnectX-7 card.
17
18 GND GND BAR 18
19 PCIE_CX_CPU_3P Micro coax 38 Connect from the
White Cabline CA-II
Plus harness to the
PCIe x16 Rx lanes of
the CPU/GPU/End-
Point. 220nF caps
are required on this
signal on the
ConnectX-7 card.
19

Nvidia ConnectX-7 Specifications

General

Supported Protocols	Ethernet, InfiniBand
RoHS Compliance	Yes
Ports	1 or 2 ports
Data Transfer Rate	Up to 400 Gb/s
Ethernet Speeds	10/25/40/50/100/200/400
InfiniBand Speeds	400Gb/s
Latency	Sub-600 nanoseconds
Form Factor	OCP 3.0
Product Type	Network Interface Card (NIC)
Power Consumption	Varies by model and configuration
