Feature Parameter Values
LLDP Client Setting
1
LLDP_NB_DCBX_P1
Enable DCBX for the first port
(applicable when LLDP_NB_TX_MODE
and LLDP_NB_RX_MODE are in ALL
mode)
False: Disable
True: Enable
LLDP_NB_DCBX_P2
Enable DCBX for the second port
(applicable when LLDP_NB_TX_MODE
and LLDP_NB_RX_MODE are in ALL
mode)
False: Disable
True: Enable
LLDP_NB_RX_MODE_P1
Enable the internal LLDP client, and
define which TLV it will process.
0x0: OFF - Not listen for
incoming LLDP BPDU
(incoming LLDP frames
will be routed to the host)
0x1: MANDATORY - Listen
for incoming LLDP frames,
store only the mandatory
LLDP BPDUs (1..3)
0x2: ALL - Receive and
store all incoming LLDP
BPDUs
LLDP_NB_RX_MODE_P2
Enable the internal LLDP client, and
define which TLV it will process.
0x0: OFF - Not listen for
incoming LLDP BPDU
(incoming LLDP frames
will be routed to the host)
0x1: MANDATORY - Listen
for incoming LLDP frames,
store only the mandatory
LLDP BPDUs (1..3)
0x2: ALL - Receive and
store all incoming LLDP
BPDUs
LLDP_NB_TX_MODE_P1
Select which LLDP TLV will be
generated by the NIC
0x0: OFF – NIC inter- nal
LLDP client will not send
LLDP frames
0x1: MANDATORY –
Transmit only manda- tory
LLDP BPDU (ChassisID,
PortID & TTL)
0x2: ALL - Transmit
optional LLDP BPDU if
configured
