Nvidia MSTFLINT User Manual

40
•
•
•
Feature Parameter Values
LLDP_NB_TX_MODE_P2
Select which LLDP TLV will be
generated by the NIC
0x0: OFF – NIC inter- nal
LLDP client will not send
LLDP frames
0x1: MANDATORY –
Transmit only manda- tory
LLDP BPDU (ChassisID,
PortID & TTL)
0x2: ALL - Transmit
optional LLDP BPDU if
configured
QoS Configuration
1
NUM_OF_TC_P1
Number of traffic classes, when DCB-X
is enabled, this is the maximum
number of TC that can negotiated with
the remote peer.
8_TCS: 0x0
1_TC: 0x1
2_TCS: 0x2
3_TCS: 0x3
4_TCS: 0x4
5_TCS: 0x5
6_TCS: 0x6
7_TCS: 0x7
NUM_OF_TC_P2
Number of traffic classes, when DCB-X
is enabled, this is the maximum
number of TC that can negotiated with
the remote peer.
8_TCS: 0x0
1_TC: 0x1
2_TCS: 0x2
3_TCS: 0x3
4_TCS: 0x4
5_TCS: 0x5
6_TCS: 0x6
7_TCS: 0x7
NUM_OF_VL_P1
Number of InfiniBand Virtual Lanes for
this port.
15_VLS: 0x5
1_VL: 0x1
2_VLS: 0x2
4_VLS: 0x3
8_VLS: 0x4
NUM_OF_VL_P2
Number of InfiniBand Virtual Lanes for
this port.
15_VLS: 0x5
1_VL: 0x1
2_VLS: 0x2
4_VLS: 0x3
8_VLS: 0x4
LLDP NB DCBX
1
DCBX_CEE_P1
Enable DCBX in CEE mode.
False: Disable
True: Enable
DCBX_CEE_P2
Enable DCBX in CEE mode.
False: Disable
True: Enable
DCBX_IEEE_P1
Enable DCBX in IEEE mode.
False: Disable
True: Enable
