Oki C3400N Maintenance Manual

Oki Data CONFIDENTIAL
43163501TH Rev. 1 108 /
7.5.1 LED Message List
(1) Status. Warning. Alarm
The Staus.Warning.Alarm list is recorded in table 7-1-1. The marks of the lighting pattern of
LED mean as follows.
It describes in the table referring to the error code (numerical value of the treble) displayed
in LCD display.
●
●
1
2
3
4
●
●
1
2
3
-
Marks Marks
Irregularity
Turning off
Lighting 1
Blinking 1 (2S cycle)
Blinking 2 (500mS cycle)
Blinking 3 (120mS cycle)
Blinking 4
(4.5S for lighting,500mS for turning off)
It displays, while not having determined the system
display language immediately after turning on a power
supply.
If a display language is determined, it will change to the
display of Priority 2.
The controller side is initializing.
Indicates that EEPROM of the controller side is being
reset.
The condition that EEPROM is reset includes the
followings.
• Changes of CU ROM (when disagreement of CU F/
W version is detected)
• Changes of destination channel
• Compulsive initialization of EEPROM (System
maintenance menu)
• OEM set of PJL command
RAM checking. The rate of checked capacity to the
total capacity is displayed on the 2nd line.
The network is in initializing.
Displays that the content of Flash memory is being
checked.
It is displayed it when Resident/Option Flash memory
not fomented are detected, or "MAINTENANCE
MENU"-"FLASH FORMAT" of a system maintenance
menu is performed.
The function mentioned above is secret to users.
Therefore, this status does not occur in a user
environment.
Displays that Flash memory is being formatted.
It is displayed it when Resident/Option Flash memory
not fomented are detected, or "MAINTENANCE
MENU"-"FLASH FORMAT" of a system maintenance
menu is performed.
The function mentioned above is secret to users.
Therefore, this status does not occur in a user
environment.
Table 7-1-1 Status Warning Alarm List
1
2
3
4
5
7
8
Priority Level Function
Initializing
Initializing
Initializing
Initializing
Initializing
Initializing
Initializing
LED Blinking Pattern PL
Status CodeONLINE PAPER ALERT
-
-
-
-
-
-
-
2
2
2
2
2
2
2
2
2
2

Oki C3400N Specifications

Paper Handling

standard paper input capacity	250 sheets
multi-purpose tray capacity	single-sheet
manual duplex printing	yes

Performance

print speed color	16 ppm
print speed mono	20 ppm
time to first page color	13 sec.
time to first page mono	9 sec.
print resolution	1200 x 600 dpi
duty cycle	35, 000 pages/month

Paper Sizes and Weights

main tray paper size range	4.1" x 5.8" to 8.5" x 14"
multi-purpose tray paper size range	3" x 5" to 8.5" x 47.24"
main tray paper weight range	17 lb. to 32 lb. bond
manual feed paper weight range	20 lb. bond to 110 lb. bond

Memory

standard memory	32 MB
maximum memory	288 MB

Supplies

standard toner cartridge life color	1, 000 pages
standard toner cartridge life black	1, 500 pages
high-capacity toner cartridge life color	2, 000 pages
high-capacity toner cartridge life black	2, 500 pages
image drum life	15, 000 pages

Weight and Dimensions

width	14.8"
depth	18.9"
height	11.4"
weight	46.2 lb.
