Oki C3400N Maintenance Manual

Oki Data CONFIDENTIAL
43163501TH Rev. 1 158 /
7.5.2.(15) Dew Condensation Errors (Error 123)
(15-1) Dew Condensation
Connection of main board
(BLA PCB) and high-voltage
board
Connection of main board
(BLA PCB) and high-voltage
board
Extreme change of
environment condition
Confirmation Tasks
Check whether 12-pole FFC is normally connected with the
HVOLT connector of main board (BLA PCB).
Check whether 12-pole FFC is normally connected with the CN1
connector of high-voltage board.
Check whether incompletely connection and oblique insertion
occurs.
Check the wire-break by tester. By visual inspection, check
whether peeling off of coating occurs.
Is environment temperature changed from low to high in a short
time?
(For example, move from cold storage area to office
environment.)
Action at NG
Reinsert the cable
normally.
Replace FFC with a
new one.
After moving the printer
to the new environment
for about one hour till it
adapts to new
environment, turn on
the printer again.
Before turning on the
printer, please check
the temperature of
sheet metal of rear
control panel and inner
sheet metal by hand
and check that the
difference between the
above and room
temperature doesn’t
exist, then turn on
again.
(15-1-1) Check of the connection
(15-1-2) Environment condition
Confirmation Items

Oki C3400N Specifications

Paper Handling

standard paper input capacity	250 sheets
multi-purpose tray capacity	single-sheet
manual duplex printing	yes

Performance

print speed color	16 ppm
print speed mono	20 ppm
time to first page color	13 sec.
time to first page mono	9 sec.
print resolution	1200 x 600 dpi
duty cycle	35, 000 pages/month

Paper Sizes and Weights

main tray paper size range	4.1" x 5.8" to 8.5" x 14"
multi-purpose tray paper size range	3" x 5" to 8.5" x 47.24"
main tray paper weight range	17 lb. to 32 lb. bond
manual feed paper weight range	20 lb. bond to 110 lb. bond

Memory

standard memory	32 MB
maximum memory	288 MB

Supplies

standard toner cartridge life color	1, 000 pages
standard toner cartridge life black	1, 500 pages
high-capacity toner cartridge life color	2, 000 pages
high-capacity toner cartridge life black	2, 500 pages
image drum life	15, 000 pages

Weight and Dimensions

width	14.8"
depth	18.9"
height	11.4"
weight	46.2 lb.
