Oki C3400N Maintenance Manual

Oki Data CONFIDENTIAL
43163501TH Rev. 1 159 /
Confirmation Tasks
Confirm that genuine toner cartridges with a tag
attached are used.
Print out the menu map by continuation of operation by
opening/closing the cover restoring the power, and
check STC mode/NTC mode and installation of
STC/NTC.
Check the menu map for the following values.
ET: ················*
KYMC-****
Every toner cartridge is in STC mode when the least
significant digit of ET is F, or in NTC mode when 0.
Every toner cartridge is in STC when the KYMC value is
0000, or in NTC mode when 1111.
If STC is installed in NTC mode, the non-installation
error occurs.
Action at NG
Replace with a
genuine spare toner
cartridge that is not
the starter toner
cartridge.
Replace with a
genuine spare toner
cartridge that is not
the starter toner
cartridge.
(16-1-1) Check attachment of the tag
(16-1-2) Check mode of toner cartridges
Confirmation Items
Attachment status of the
RFID tag
Starter toner cartridge
mode (STC)
or
Normal toner cartridge
mode (NTC)
7.5.2.(16) RFID Related Error (Error 610-613)
(16-1) A toner cartridge not installed
Confirmation Tasks
Check the status monitor for error details.
Error: 554-557, 614-617, 620-623
Action at NG
Replace with a
usable genuine
spare toner cartridge
that is not a starter
toner cartridge.
(16-2-1) Check for a toner cartridge of different type
Confirmation Items
Check the toner cartridge
(16-2) Detection of an OKIDATA toner cartridge of different type
Confirmation Tasks
Check the status monitor for error details.
Error: 550-553
Action at NG
Replace with a
usable genuine
spare toner cartridge
that is not a starter
toner cartridge.
(16-3-1) Check for a non-genuine toner cartridge
Confirmation Items
Check the toner cartridge
(16-3) Detection of a non-OKIDATA toner cartridge
Confirmation Tasks
Check the connection of it to the BLA (main) board, the
LUM (RFID reader writer) board, and the POL (RFID
antenna PCB) board.
Action at NG
Reconnect the
poorly connected
cable. If the same
error occurs in
rechecking, replace
the LUM board
and/or BLA board.
(16-4-1) Check the connection
Confirmation Items
Check the connection of
the RFID PCB
(16-4) RFID communication error

Oki C3400N Specifications

Paper Handling

standard paper input capacity	250 sheets
multi-purpose tray capacity	single-sheet
manual duplex printing	yes

Performance

print speed color	16 ppm
print speed mono	20 ppm
time to first page color	13 sec.
time to first page mono	9 sec.
print resolution	1200 x 600 dpi
duty cycle	35, 000 pages/month

Paper Sizes and Weights

main tray paper size range	4.1" x 5.8" to 8.5" x 14"
multi-purpose tray paper size range	3" x 5" to 8.5" x 47.24"
main tray paper weight range	17 lb. to 32 lb. bond
manual feed paper weight range	20 lb. bond to 110 lb. bond

Memory

standard memory	32 MB
maximum memory	288 MB

Supplies

standard toner cartridge life color	1, 000 pages
standard toner cartridge life black	1, 500 pages
high-capacity toner cartridge life color	2, 000 pages
high-capacity toner cartridge life black	2, 500 pages
image drum life	15, 000 pages

Weight and Dimensions

width	14.8"
depth	18.9"
height	11.4"
weight	46.2 lb.
