7.5.3.(4) Vertical lines are printed
(4-1) Thin vertical lines (with color) (See Figure 7.2 D )
Filming of ID unit
Confirmation Tasks
Print without toner?
Action at NG
Replace the toner
cartridge with a new
one. If trouble is
occurred again after
replacing, please
replace ID unit with a
new one. When trying
to use a new ID unit,
please be careful not
to break the fuse with
jig inside the ID unit.
(Please refer to page
132)
(4-1-1) ID unit condition
Confirmation Items
(4-2) Thin vertical lines (without color) (See Figure 7.2 F )
LED head
Feeding route
Confirmation Tasks
Does any foreign adhere to light-emitting surface of SELFOC
lens of LED head?
Check whether the barricade resulted from unfixed toner
scratched during unfixed paper transport route exists.
Action at NG
Remove the foreign.
Remove the
barricade.
(4-2-1) LED head condition
(4-2-2) Paper feeding condition
Confirmation Items

Oki C3400N Specifications

Paper Handling

standard paper input capacity	250 sheets
multi-purpose tray capacity	single-sheet
manual duplex printing	yes

Performance

print speed color	16 ppm
print speed mono	20 ppm
time to first page color	13 sec.
time to first page mono	9 sec.
print resolution	1200 x 600 dpi
duty cycle	35, 000 pages/month

Paper Sizes and Weights

main tray paper size range	4.1" x 5.8" to 8.5" x 14"
multi-purpose tray paper size range	3" x 5" to 8.5" x 47.24"
main tray paper weight range	17 lb. to 32 lb. bond
manual feed paper weight range	20 lb. bond to 110 lb. bond

Memory

standard memory	32 MB
maximum memory	288 MB

Supplies

standard toner cartridge life color	1, 000 pages
standard toner cartridge life black	1, 500 pages
high-capacity toner cartridge life color	2, 000 pages
high-capacity toner cartridge life black	2, 500 pages
image drum life	15, 000 pages

Weight and Dimensions

width	14.8"
depth	18.9"
height	11.4"
weight	46.2 lb.
