A-1 43216001 Belt-Unit (PX732)
Apply MOLYKOTE (EM-30L) to the hatched area.
EM-30L Class C
Guide-R
Guide-L
Apply MOLYKOTE (EM-30L) to the hatched area.
EM-30L Class C
Bracket-CL-Assy.
Not applying grease to a part of a metal plate.
Bracket-CL-L
