3. Maintenance
2
Press the open button (A) and open the output tray (a).
3
Take all the four image drums out of the machine, and then place them on a
flat surface.
4
Cover the image drums you took out with paper so that the image drums do
not expose to the light.
5
Turn the lock levers (b) on the both sides of the belt unit forward to unlock.
6
Remove the belt unit by holding the lock lever (b).
Possible to get burned.
The fuser unit is extremely hot. Do not touch it.
To Next Page
