Chapter 11: Bar Code Commands for 24-Pin Printers118
Select Interleaved 2 of 5 Bar Code Command
The command for selecting Interleaved 2 of 5 is
ESC DLE A m 3 0 n
3
n
4
n
5
n
6
n
7
n
8
Interleaved 2 of 5 Parameters n
3
and n
4
These parameters set the vertical length of the bars in units of 15/180", as calculated by the
equation
[(n
3
x 10) + n
4
] x 15/180"
where the total value must be less than or equal to 25.
Interleaved 2 of 5 Parameter n
5
Parameter n
5
is used in combination with parameter n
7
to set the width of one character of the
black bars, as follows:
Table 92: IBM/Epson Select Interleaved 2 of 5 Command —
Black Bar Widths for Parameter n
5
, n
7
Values (24-Pin Printers)
n
5
= 1 n
5
= 2 n
5
= 3 n
5
= 4 n
5
= 5 n
5
= 6 n
5
= 7
n
7
= 1
n
7
= 2
n
7
= 3
n
7
= 4
n
7
= 5
n
7
= 6
n
7
= 7
20/360"
24/360"
30/360"
34/360"
40/360"
44/360"
50/360"
34/360"
40/360"
48/360"
54/360"
62/360"
68/360"
76/360"
55/360"
65/360"
75/360"
85/360"
93/360"
103/360"
115/360"
69/360"
81/360"
93/360"
105/360"
117/360"
129/360"
141/360"
90/360"
100/360"
120/360"
134/360"
150/360"
164/360"
180/360"
184/360"
120/360"
138/360"
154/360"
172/360"
188/360"
206/360"
125/360"
145/360"
165/360"
185/360"
205/360"
225/360"
245/360"
Interleaved 2 of 5 Parameter n
6
Parameter n
6
is used in combination with parameter n
7
to set the width of one character of the
spaces, as follows:
Table 93: IBM/Epson Select Interleaved 2 of 5 Command —
Space Widths for Parameter n
6
n
7
Values (24-Pin Printers)
n
6
= 1 n
6
= 2 n
6
= 3 n
6
= 4 n
6
= 5 n
6
= 6 n
6
= 7
n
7
= 1
n
7
= 2
n
7
= 3
n
7
= 4
n
7
= 5
n
7
= 6
n
7
= 7
50/360"
56/360"
60/360"
66/360"
70/360"
76/360"
80/360"
64/360"
72/360"
78/360"
86/360"
92/360"
100/360"
106/360"
85/360"
95/360"
105/360"
115/360"
125/360"
135/360"
146/360"
99/360"
111/360"
123/360"
135/360"
147/360"
159/360"
171/360"
120/360"
136/360"
150/360"
166/360"
180/360"
196/360"
210/360"
134/360"
152/360"
168/360"
186/360"
202/360"
220/360"
236/360"
155/360"
175/360"
195/360"
215/360"
235/360"
255/360"
275/360"
