OKIDATA ML395C - Page 265

Item Okidata P/N
Oki-J P/N
Description Comments
Refer to B.1.02
Disassembly
Procedure
1 70021601
N/A
Bottom Tractor Feed
Unit (Push)
Option
3.2.30
2 50215901
4YA4043-4280G1
Pull-Up Roller
Assembly
Option RSPL N/A
3 50212604
2PA4016-4722G4
Cover: Acoustic
(Pull Tractor) BTF
Option RSPL N/A
4 55066102
4YA4042-1513G2
PCB: BTFD-2 (BTF) Option RSPL
3.2.31
5 50922001
4PP4043-4300P1
Spring: (BTF) Option RSPL
3.2.32
6 51002201
4PP4025-2653P1
Guide: Sheet (BTF) Option RSPL
3.2.33
7 53063701
3PA4094-6159G1
Door: Front
(Assembly) (BTF)
Option RSPL
3.2.34
8 51228801
3PP4053-2693P1
Pulley: Drive (BTF)
(ML395)
Option RSPL
3.2.35
9 54111291
4LP-1313-191
Belt: Mini Pitch (125
teeth)
Option RSPL
3.2.35
10 56509401
3PB4043-4249P1
Motor: Line Feed
(BTF)
Option RSPL
3.2.36
11 50057402
4PA4043-2684G2
Tractor: Pin (Left)
BTF
Option RSPL
3.2.37
12 50057502
4PA4043-2685G2
Tractor: Pin (Right)
BTF
Option RSPL
3.2.37
NOTE: The Pull-Up Roller Assembly is part of the Bottom Push Tractor Unit.
