OKIDATA ML395C - Ribbon Shift Arm Spring; Ribbon Shift Arm

Page: 58
Service Guide ML395/395C
Chapter 3 Maintenance & Disassembly
3.2.24 Ribbon Shift Arm Spring / Ribbon Shift Arm
Microline 395C - Color Model Only
1. Detach the printer access cover.
2. Remove the ribbon cartridge (1).
3. Remove the shift arm spring (2).
4. Remove the 7 mm mounting bolt (3) and detach the ribbon shift arm (4).
P/N 50315401 Screw (Color) RSPL B.2.05
P/N 50924001 Spring: Shift Arm (Color) RSPL B.2.05
P/N 53478901 Arm: Ribbon Shift (Color) RSPL B.2.05
