Page: 48
Service Guide ML395/395C
Chapter 3 Maintenance & Disassembly
3.2.14 Space Motor Assembly
1. Remove the printhead (3.2.01).
2. Remove the ribbon feed assembly (3.2.13).
3. Loosen the two belt pulley bracket mounting screws (1).
4. While pushing the belt pulley bracket (2) to the left, temporarily tighten the two screws. This will ease
the tension on the space belt.
5. Remove the three space motor mounting screws (3).
6. Using needle-nosed pliers, detach the nylon cable clamp (4) from the cooling fan.
7. Remove the space motor (5) by pulling it toward the front of the printer.
P/N 56506205 Motor: Space (ML395) RSPL B.2.06
, 09
