Service Guide ML395/395C
Chapter 3 Maintenance & Disassembly
3.2.04 Upper Cover Assembly
1. Disconnect the interface cable (1).
2. Detach the platen knob (2).
3. Remove the two cover mounting screws (3) at the rear of the printer.
4. Lift the rear access cover (4) to the open position.
5. Lift the upper cover at the back and tilt it towards the front to remove it.
NOTE:
When installing the upper cover assembly:
Move the release lever (5) towards the front of the printer.
Move the bail arm lever (6) towards the back of the printer.
Check that the paper bail moves properly.
P/N 50212441 Cover: Middle Assembly RSPL B.2.01
P/N 50212442 Cover: Middle Assembly RSPL B.2.01 (Color)
P/N 50215701 Cover: Access (ML395) RSPL B.2.01
P/N 50215703 Cover: Access (ML395C) RSPL B.2.01
P/N 50215801 Cover: Rear Assembly RSPL B.2.01
P/N 53478601 Platen Knob RSPL B.2.02
