OKIDATA ML395C - Ribbon Feed Assembly

Page: 47
Service Guide ML395/395C
Chapter 3 Maintenance & Disassembly
3.2.13 Ribbon Feed Assembly
1. Remove the printer mechanism (3.2.08).
2. Remove the two ribbon cartridge bracket mounting screws (1).
3. Detach the cartridge bracket (2).
4. Remove the two mounting screws (3).
5. Detach the ribbon feed assembly (4).
NOTE:
When assembling, install the ribbon drive assembly so that the gear teeth contact properly (5).
The gears must not bind together.
P/N 50054301 Feed: Ribbon Assembly RSPL B.2.06 , 09
