OKIDATA ML395C - Cooling Fan

Page: 50
Service Guide ML395/395C
Chapter 3 Maintenance & Disassembly
3.2.16 Cooling Fan
1. Remove the printer mechanism (3.2.08).
2. Remove the two ribbon cartridge bracket mounting screws (1).
3. Detach the cartridge bracket (2).
4. Using needle-nosed pliers, detach the nylon cable clamp (3) from the fan cover (4).
5. Remove the two fan cover mounting screws (5).
6. Remove the cooling fan / fan cover assembly.
7. Remove the two cooling fan mounting screws (6).
8. Detach the cooling fan (7).
P/N 56509501 Fan: Cooling RSPL B.2.06
