Service Guide ML395/395C
Chapter 3 Maintenance & Disassembly
3.2.26 Ribbon Guide
1. Remove the printhead (3.2.01).
2. Loosen the 7 mm ribbon shift arm mounting bolt (1) and detach the ribbon shift arm (2) from
projection A of the ribbon guide (3).
3. Remove the two printhead mounting screws.
4. Lift the printhead from the printer. As you lift the printhead, the ribbon guide can be removed.
P/N 50605701 Ribbon Guide Post (Color) B.2.05
P/N 53056002 Guide: Ribbon (Color) RSPL B.2.05
