Service Guide ML395/395C
Chapter 3 Maintenance & Disassembly
3.2.11 Head Cable Assembly
1. Detach the printhead (3.2.01).
2. Remove the printer mechanism (3.2.09).
3. Work from the bottom of the printer mechanism and loosen the two mounting screws (1).
4. Detach tabs (A) and (B) from the frame and remove the cable holder (2).
5. Remove the two ribbon cartridge bracket mounting screws (3).
6. Detach the cartridge bracket (4).
7. Remove the mounting screw (5)
8. Detach the connector clamp (6).
9. Detach the head cable connector (7) from the carriage frame (8).
10. Lift the front of the printer mechanism and remove the head cable assembly by pulling downward.
P/N N/A Clamp B.2.04
, 05
P/N 56614201 Cable: Printhead (Assembly) RSPL B.2.04 , 05 , 12
