ARYAL S2 E DUAL / TRIAL
ENGLISH
EN - 21
7. Thread this pipeline through the wall and connect it to the outdoor unit.
8. Insulate all the piping, including the valves of the outdoor unit.
9. Open the stop valves of the outdoor unit to start the ow of the refrigerant between the indoor and outdoor
unit.
Checkthatthereisnoleakageofrefrigerantaftercompletinginstallationoperations.
In the event of leakage of refrigerant, immediately ventilate the area and evacuate the system.
8 - WIRING
• All wiring must comply with local and national electrical codes, regulations and must be
installed by a licensed electrician.
 • AllelectricalconnectionsmustbemadeaccordingtotheElectricalConnectionDiagram
located on the panels of the indoor and outdoor units.
 • Ifthereisaserioussafetyissuewiththepowersupply,stopworkimmediately.Explain
your reasoning to the client, and refuse to install the unit until the safety issue is properly
resolved.
 • Powervoltageshouldbewithin90-110%ofratedvoltage.Insufcientpowersupplycan
cause malfunction, electrical shock, or re.
• Only connect the unit to an individual branch circuit outlet. Do not connect another appli-
ance to that outlet.
• Make sure to properly ground the air conditioner.
 • Everywiremustbermlyconnected.Loosewiringcancausetheterminaltooverheat,
resulting in product malfunction and possible re.
• Do not let wires touch or rest against refrigerant tubing, the compressor, or any moving
parts within the unit.
 • Iftheunithasanauxiliaryelectricheater,itmustbeinstalledatleast1meterawayfrom
any combustible materials.
• Make sure that you do not cross your electrical wiring with your signal wiring.
• This may cause distortion and interference.
• The unit must be connected to the main outlet. Normally, the power supply must have a
impedance of 32 ohms.
• No other equipment should be connected to the same power circuit.
 • Connecttheoutdoorwiresbeforeconnectingtheindoorwires.
 MAKESURETHAT:
 • Thepowersupplyvoltageandfrequencyvaluesrespectthatspeciedontheappliance
data plate.
• The power supply line has an effective earth connection and it is correctly dimensioned
formaximumabsorptionoftheclimatecontrolunit.
• A suitable omnipolar disconnection device must be envisioned on the appliance mains
electric power supply, in compliance with the national installation rules.
It must be checked that the electric power supply has an effective earth and suitable pro-
tections against overloads and/or short circuits.
The use of a ceramic fuse of the characteristics shown in the table is advised (or other
devices with the same functions).
 • BEFOREMAKINGTHEELECTRICCONNECTION,MAKESURETHATTHEUPSTREAMISO-
LATINGSWITCHISAT“0”(OFF)ANDTHEPROTECTIONSOFTHEINDOORANDOUTDOOR
UNITSAREPOSITIONEDCORRECTLY.
BEFOREPERFORMINGANYELECTRICALORWIRINGWORK,TURNOFFTHEMAINPOWER
TOTHESYSTEM.
