About this machine
2
2-12 d-Color MF222 plus/MF282 plus/MF362 plus/MF452 plus/MF552 plus
2.2
Rear side
The illustration shows the main unit that contains the Heater and Fax Kit.
The shape of the power cord varies depending on the sales region.
The Heater is provided as an optional unit depending on the sales areas.
d Reference
For details, refer to the [User's Guide Online] on the DVD.
No. Name
1 Telephone Jack 1/2 (LINE PORT 1/2)
2 Jack for connecting a telephone (TEL PORT1/2)
3 Power Cord
4 Power switch for dehumidifying heater
5 USB Port (Type A) USB2.0/1.1
6 Network Connector (10Base-T/100Base-TX/1000Base-T)
7 USB Port (Type B) USB2.0/1.1
