2KR/2KS
1-1-6
Figure 1-1-3
B1
A2
DP
OPT2
OPT1
21
22
23 24
25
29
32
33
30
31
26
27
28
21. USB memory slot (A1)
22. Front cover
23. Paper width adjusting tab
24. Paper length guide
25. Top tray
26. Main power switch
27. Paper width guide
28. MP tray (multi purpose tray)
29. Optional interface slot (OPT2)
30. USB memory slot (A2)
31. USB interface connector (B1)
32. Network interface connector
33. Optional interface slot (OPT1)
Service Manual Y111960-2
