2KR/2KS
1-3-10
U000
Maintenance
item No.
Description
No. Items Description
(3)
cont.
Paper Jam Log (e) Detail of paper exit location (Hexadecimal)
01: Face down (FD)
02: Face up (FU)/
Document finisher face up (FU)/
3000-sheet document finisher left sub tray (FU)
03: Document finisher face down (FD)
04: Reserved
05: Reserved
06: 3000-sheet document finisher right sub tray (FU)
07: 3000-sheet document finisher left sub tray (FD)
09: 3000-sheet document finisher right sub tray (FD)
0B: Mailbox tray 1 (FD)
0C: Mailbox tray 1 (FU)
0D: Reserved
0E: Reserved
15: Mailbox tray 2 (FD)
16: Mailbox tray 2 (FU)
1F: Mailbox tray 3 (FD)
20: Mailbox tray 3 (FU)
29: Mailbox tray 4 (FD)
2A: Mailbox tray 4 (FU)
33: Mailbox tray 5 (FD)
34: Mailbox tray 5 (FU)
3D: Mailbox tray 6 (FD)
3E: Mailbox tray 6 (FU)
47: Mailbox tray 7 (FD)
48: Mailbox tray 7 (FU)
(4) Service Call Log # Count. Service Code
Remembers 1 to 8 of
occurrence of self diag-
nostics error. If the
occurrence of the previ-
ous diagnostics error is
less than 8, all of the
diagnostics errors are
logged.
The total page count at
the time of the self
diagnostics error.
Self diagnostic error
code
(See page 1-4-26)
Example:
01.6000
01: Self diagnostic
error
6000: Self diagnostic
error code number
(5) Maintenance Log # Count. Item
Remembers 1 to 8 of
occurrence of replace-
ment. If the occurrence
of the previous replace-
ment of toner container
is less than 8, all of the
occurrences of replace-
ment are logged.
The total page count at
the time of the replace-
ment of the toner con-
tainer.
Code of maintenance
replacing item (1 byte,
2 categories)
First byte (Replacing
item)
01: Toner container
02: Maintenance kit
Second byte (Type of
replacing item)
00: Fixed
Service Manual Y111960-2
To Next Page
