CAUTION - Safety symbols -
The following symbols are placed on this product.
Study the meaning of the symbols and always use the product in the safest possible manner.
Symbol Meaning
Indicates a non-specific general hazard. Follow the description given after this symbol or in the
instruction manual.
Indicates that the surface becomes hot, and should not be touched with bare hands. It may cause
burns.
Indicates high voltage. Take special care to prevent electric shock.
Indicates that care is required against your finger or hand being caught.
Indicates that the seesaw type main switch is ON.
(Seesaw type is the type of switch where ON or OFF is selected by pressing it to ON or OFF side.)
Indicates that the seesaw type main switch is OFF.
Label position and instruction
The labels are attached to the portions which require special cautions during use and operation. Be sure to follow these
instructions.
Label position Label
Instructions in instruction
manual
Page
Lower back of microscope frame /
Center on the rear of microscope frame /
Right side of microscope frame
External power supply for halogen bulb (TH4-100/TH4-200) /
Motorized Revolving nosepiece (U-P5REMC / U-D6REMC /
U-D5BDREMC / U-P5BDREMC / U-D6BDREMC)
Caution for electric safety 3
Caution for prevention of electric
shock
5
Mount of lamp housing for reflected light illumination /
DF converter (U-RCV) /
Adapter for the mercury lamp housing (MX-HGAD) /
Double lamp housing adapter (U-DULHA) /
100W halogen lamp housing for IR (U-LH100IR) /
100W halogen lamp housing (U-LH100L-3) /
High temperature 4
100W mercury lamp housing (U-LH100HG)
100W mercury apo lamp housing (U-LH100HGAPO)
Light source (U-HGLGPS)
High temperature 4
Electric shock 4
External power supply for mercury burner (U-RFL-T)
Electric shock 4
14x12-inch stage (MX-SIC1412R2)
Pinch hazard 27
ND filter slider (U-25ND25-25/U-25ND25/U-25ND6) /
Frost filter slider (U-25FR) /
Interference contrast filter slider (U-25IF550) /
L42 filter slider (U-25L42) /
Light balancing filter slider (U-25LBD) /
Yellow filter slider (U-25Y48) /
Empty slider (U-25) /
Light balancing amber filter slider (U-25LBA)
High temperature 75
When caution labels are dirty or peeled off, contact Olympus for replacement or inquiries.
