2828
· In order to prevent the sample from colliding with the
objective, be sure to change the objective in order from
the low magnification to the high magnification before
focusing.
· Do not rotate the revolving nosepiece directly with hand.
Rotating by hand may damage the gear heads or cause
other malfunctions.
Pressing the objective selection button
a
on the front panel will rotate
the revolving nosepiece in the
direction by one step. To rotate it in
the opposite direction, press the other objective selection button
b
to rotate in
direction.
Pressing this objective selection button for multiple times
consecutively allows you to select the desired objective.
1
3-6 Selecting the objective
When the hand switch is combined
The lighting of the OB indicator
c
of the hand switch (BX3M-HS)
changes according to the objective selection button.
b
a
c
