Olympus MX63 - Replacement of Optical Parts; Removing and Attaching the Eyepiece

63
MX63/MX63L
63
6 Replacement of optical parts
1
Removing the eyepiece
2
Attaching the eyepiece micrometer
b
a
Pull out the eyepiece
a
from the eyepiece sleeve
b
.
1
a
b
You can use the eyepiece micrometer to check the size of the observed
image or the center position of the observation field of view, etc. For
the eyepiece micrometer types attachable to your eyepiece, contact
Olympus.
Attachable eyepiece micrometer
Size
Ø24 mm Thickness 1.5 mm
Hold the eyepiece frame, and rotate the built-in reticle holder
a
in
the arrow direction to remove it.
Depending on the case, the reticle holder may be tightened
too firmly and it cannot be rotated. If you grab the reticle
holder too firmly, it will be deformed and cannot be rotated
furthermore. Grab around the reticle holder lightly with equal
force to rotate or push it to the rubber sheet placed on the
desk to rotate and remove it.
Insert the eyepiece micrometer
b
in the removed reticle holder
a
with the display surface of the eyepiece micrometer facing down.
Screw in the reticle holder
a
to the bottom of the eyepiece.
· Be careful not to touch the lens with your fingers during
operation.
· Do not tighten the reticle holder with excess force.
1
TIP
2
3
NOTE
1
6-1 Removing and attaching the eyepiece
2
