4444
(Can be set to the BF position if there is sufficient brightness)
Observation
3
[Trinocular tube only]
Push in the light path selection knob.
4
Remove the analyzer and the
polarizer from the light path.
1
Set the main switch of the microscope frame
to
(ON) and set the light intensity knob
to the low voltage position.
5
Set the main switch of the light source to (ON).
7
Engage the 5X or 10X objective in the light path
using the objective selection button and
bring the sample into focus.
Engage the objective with the magnificati
on to be used in the light path and
bring the sample into focus.
Set the observation light path selection knob
to the DF (reflected light darkfield) position.
Insert the required filters.
12
Adjust the brightness.
8
Adjust the brightness.
14
Adjust the field diaphragm and
aperture diaphragm.
Adjust the interpupillary distance.
10
Adjust the diopter.
6
Place a sample for observation on the stage.
5-1 Transmitted light brightfield observation procedures
5 Observation methods
The dummy slider in the DIC prism insertion slot is effective for preventing flare in observations other than the DIC
observation. It is, therefore, recommended to leave it mounted in any observation method.
Setting the DF light path prevents the half mirror from entering the transmitted light illumination light path.
Therefore, the transmitted light can be used most effectively.
Main switch P.46
Light intensity knob P.46
Observation light path selection knob P.25
Light path selection knob P.26
Objective selection button P.28
Light intensity volume knob P.46
X-axis/Y-axis knobs P.27
Main switch P.46
Filter insertion slot P.49
Light intensity volume knob P.46
Operation part Page
Objective selection button P.28
Coarse focusing knob / Fine focusing
knob
P.29
Field diaphragm lever (MX-TILLB) P. 4 7
Condenser height adjustment ring
(MX-TILLB)
P.47
Aperture diaphragm lever or aperture
diaphragm ring
P.48
Interpupillary distance adjustment
scale
P.35
Diopter adjustment ring P.35
To Next Page
