MX63/MX63L
57
Set the main switch to (ON).
Place a sample for observation on the stage.
Use the objective selection button to engage
the 5X or 10X objective in the light path and
bring the sample into focus.
Adjust the interpupillary distance.
Adjust the diopter.
Insert the required filters.
Use only for fine adjustment of aperture
diaphragm during brightfield observation.
Adjust the brightness
(illumination voltage).
Engage the objective with the magnification to be used
in the light path and bring the sample into focus.
Observation
[Trinocular tube only]
Push in the light path selection knob.
Select BF (reflected light brightfield observation).
Remove the analyzer, mirror unit, etc. from
the light path.
Adjust the brightness.
Insert the MIX slider for reflected light observation.
Main switch P.24
Observation light path selection knob P.25
Light path selection knob P.26
Light intensity knob P.32
X-axis/Y-axis knobs P.27
Light intensity knob P.32
Filter insertion slot P.39
5-6
Reflected light simultaneous observation for BF/DF observation procedures
Objective selection button P.28
Coarse focusing knob / Fine focusing
knob
P.29
Objective selection button P.28
Coarse focusing knob / Fine focusing
knob
P.29
Aperture diaphragm open/close
button
P.38
MIX slider for reflected light
observation
P.58
Operation part Page
Interpupillary distance adjustment
scale
P.35
Diopter adjustment ring P.35
To Next Page
