Problem Cause Remedy Page
e) The pilot lamp turns ON, but the
objective selection button and
the aperture diaphragm open/
close button do not turn ON.
The cable for the LED lamp
housing is not connected.
Set the main switch to
(OFF)
and connect the cable for the LED
lamp housing to the connector on
the back of the microscope frame.
96
The microscope frame or the LED
lamp housing is damaged.
Contact Olympus.
—
f) The brightness cannot be relay
when the LIM function is set.
The LIM switch is not pressed (LIM
switch in ON) or the brightness is
not stored properly.
Press the LIM switch to set the
"Replay" mode.(LIM switch is ON.)
If the LIM switch is ON, press the
LIM switch is OFF and store the
brightness properly.
33
The microscope frame or the
revolving nosepiece is damaged.
Contact Olympus.
—
g) The MIX slider for reflected light
observation (U-MIXR) cannot
be controlled by operating the
hand switch (BX3M-HS).
The MIX slider for reflected light
observation (U-MIXR) is not
engaged in the light path.
Engage the MIX slider for reflected
light observation in the light path.
You can check whether the MIX
slider for reflected light observation
is engaged or not by the POSITION
indicator of the hand switch.
58
The hand switch (BX3M-HS) is not
connected.
Set the main switch to
(OFF)
and connect the hand switch
(BX3M-HS).
96
The MIX slider for reflected light
observation (U-MIXR) is not
damaged.
Contact Olympus.
—
The MIX slider for reflected
light observation (U-MIXR) is
disconnected.
Connect the MIX slider for reflected
light observation.
96
The cable for MIX slider
(U-MIXRCBL) is disconnected.
Contact Olympus.
—
h) The CUBE or OB indicator of
the hand switch (BX3M-HS)
does not turn ON.
The hand switch (BX3M-HS) is not
connected.
Set the main switch to
(OFF)
and connect the hand switch
(BX3M-HS).
96
The microscope frame or the hand
switch (BX3M-HS) is damaged.
Contact Olympus.
—
