Optical performance
Series name Notation
Magnification
Numerical
aperture
Working
distance
(mm)
Cover glass
thickness
(mm)
Eyepiece
WHN10X (FN22) SWH10X (FN26.5)
Total
magnification
Actual field
of view
(mm)
Total
magnification
Actual field
of view
(mm)
UIS2 series
SLMPLN
Super long working distance
M Plan Achromat
(OFN26.5) **
SLMPlanN
20X 0.25 25.0 0 200X 1.1 200X 1.33
50X 0.35 18.0 0 500X 0.44 500X 0.53
100X 0.60 7. 5 0 1000X 0.22 1000X 0.27
MPLAPON
M Plan Apochromat
(OFN26.5) **
MPlanApoN
50X 0.95 0.35 0 500X 0.44 500X 0.53
100X 0.95 0.35 0 1000X 0.22 1000X 0.27
100XO2 1.45 0.1 0 1000X 0.22 1000X 0.27
LMPLN-IR
IR Long working dsistance
M Plan Achromat
(OFN22) **
LMPlan-IR
5X 0.1 23 — 50X 4.4 50X 5.3
10X 0.3 18 — 100X 2.2 100X 2.65
LCPLN-IR
IR M Plan Achromat
(OFN22) **
LCPlan-IR
20X 0.45 8.3 0-1.2 200X 1.1 200X 1.33
50X 0.65 4.5 0-1.2 500X 0.44 500X 0.53
100X 0.85 1.2 0-0.7 1000X 0.22 1000X 0.27
For liquid crystal panel
Optical performance
Series name Notation
Magnification
Numerical
aperture
Working
distance
(mm)
Cover glass
thickness
(mm)
Eyepiece
WHN10X (FN22) SWH10X (FN26.5)
Total
magnification
Actual field
of view
(mm)
Total
magnification
Actual field
of view
(mm)
UIS2 series
LCPLFLN-LCD
M Plan Semi Achromat
(OFN26.5) **
LCPlanFLN-
LCD
*
20XLCD 0.45 7.4-8.3 0-1.2 200X 1.1 200X 1.33
50XLCD 0.70 2.2-3 0-1.2 500X 0.44 500X 0.53
100XLCD 0.85 0.9-1.2 0-0.7 1000X 0.22 1000X 0.27
*
: Equipped with the correction collar according to the glass thickness.
