MF 64
Author: Donato Gavino Murru donato.gavino.murru@omgitaly.com Pag. 106 a 179
Don’t adjust the wheel excessively low on chain. Make sure to leave approximately
the thickness of material between chain and wheel. Match carefully the groove of
wheel with the pin of the chain to avoid damaging the chain and the roll. Not doing
so may result in damage to the product.
Be sure that there is no material inside rails during the width
regulations. Not doing so may result in injury or damage to the product.
Turn this hexagonal part
to modify the position of
the wheel.
The groove in the wheel is pushing
the material against the pin chain.
