Technical Data
67
Table 6-24:
Technical data of the
NET-1 communication port
ETH2
NET-1: Ethernet port ETH2
Type 100Base-FX (100Mbit, fiber, duplex)
Connector MT-RJ
Cable type 50/125 µm or 62.5/125 µm (duplex
patch cable)
Cable length > 1 km (0.62 miles) possible
Status idication Green LED: physical link present
Yellow LED: traffic on interface
This is a product of Laser Class 1
(IEC 60825)
