Technical Data
85
Table 6-43:
Sampling rate
9.48 kHz
Table 6-44:
Sampling rate
3.16 kHz
Table 6-45:
DC accuracy
Note: The accuracy specifications include linearity, temperature, ageing drift,
frequency and phase response.
Frequency range Power Accuracy
1
AC Typical Guaranteed
10 Hz ... 750 Hz S + 0.3 % / - 0.7 % ± 1.8 %
10 Hz ... 750 Hz P + 0.3 % / - 0.7 % ± 1.8 %
10 Hz ... 750 Hz Q + 0.8 % / - 1.2 % ± 2.5 %
Frequency range Power Accuracy
1
AC Typical Guaranteed
10 Hz ... 250 Hz S + 0.3 % / - 0.5 % ± 1.3 %
10 Hz ... 250 Hz P + 0.3 % / - 0.5 % ± 1.3 %
10 Hz ... 250 Hz Q + 0.8 % / - 1 % ± 2.2 %
Power Accuracy
1
1
S = Apparent power
P = Active power
Q = Reactive power
DC Typical Guaranteed
P, S ± 0.3 % ± 0.9 %
Actual - Expected
Full scale
x 100 %Relative error:
