Omnicomm Profi - Power Supply and Ignition Key

10 Not used NC
11 Line A RS-485 LLS A RS-485 LLS Orange-white
12 CAN Н CAN Н Purple-orange
No. of pin Signal name Designation Wire colour in cable
Power Supply and Ignition Key
Connect Omnicomm Profi, Profi Wi-Fi terminals as per diagrams without battery
disconnect switch:
15
Installation
